NAYBY 0,6/1kV - PVC insulated and sheathed power cable, steel tape armored
Application:
Power supply to power stations. The cables must be protected against: corozive chemicals, chemical solvents UV resistant cables
Construction:
Conductor - Solid (RE) / Stranded (RM/SM)
Insulation - Polyvinylchloride (PVC)
Blank or zinc-plated cold-rolled
Outer sheath - Polyvinylchloride (PVC) Black, UV - resistant
Standards:
Electrical Performance:
Nominal Voltage: 600/1000 Volt
Operating temperature: short circuit °C 160°C (max 5 sec)
Bending radius: Single circle x diameter 6
Bending radius: Multi core x diameter 12
Temperature range:
In motion °C -5°C till +70°C
Fixed °C -30°C till +70°C
Fire CPR class:
