Application:

This power cable is suitable for fixed installations, preferably in cable ducts, indoors, outdoors, in water or underground if no mechanical damage is to be expected

Construction:

Conductor - Solid (RE) or stranded (RM/SM) aluminium wires

Insulation - Halogen - Free, Cross linked Polyethylene

Filling - PVC core covering or taping

Outher sheath - Halogen Free Flame Retardant (HFFR)

Standards:

DIN VDE 0276-604
HD 604 S2
IEC 60228

License:

This cable is VDE certified

Electrical Performance:

Nominal Voltage: 600/1000 Volt

Test Voltage: [V]AC 4000

Short circuit time max. [sec] 5

Bending radius: Single circle x diameter 15

Bending radius: Multi core x diameter 12

Temperature range:

In motion: -5°C till +70°C

Fixed: -30°C till +90°C

Maximum short circuit temperature 160°C <=300mm2

Maximum short circuit temperature 140°C > 300mm2

Fire CPR class:

Reaction to fire 50575 - Eca

NA2XH 0,6/1kV – Halogen free cable with improved fire behaviour
